D60A-8 Bulldozer Lower Roller
Color:black,yellow,blue,gray
Mini track roller type:inner flange,outter flange
Bushing type:bearig,bimetabl bushing
mounting type:shaft bolt type,collar type
Product Introduction
Products Description
D60A-8 Bulldozer Lower Roller
Production Description
A Komatsu bulldozer lower roller is a vital component of a bulldozer's undercarriage system. It is positioned at the bottom of the equipment and is responsible for supporting the weight and ensuring smooth movement of the bulldozer.
The lower roller is comprised of a steel shell and an inner bearing which rotates on an axle. It is also equipped with precision seals and lubrication to prevent dirt and water from entering the roller.
The Komatsu bulldozer lower roller is designed to withstand harsh conditions and long-term usage. It is made of high-quality materials that ensure durability and longevity. It also reduces uneven wear and tear on the machine's tracks, which is important for long-term performance.
Advantages Of Upper Roller
1 .The design of double-cone sealing and lubrication for life makes the bulldozer lower roller have long life time and perfect performance under any working condition.
2. Bimetal bushing of our bulldozer track roller is based on steel plate which special alloy is sintered on it. It shows high loading ability and high ability of fatigue resistance.
3. Each track roller shell is carefully heat treated to ensure long wear life and stress resistance.
4. Differential type of quenching or through type of quenching heattreatment can ensure certain heat treatment hardness depth and so give good anti-cracking effects.
5. Warm forging treated roller shell gains distinguishing inner material fiber flow distribution architecture.
6.Each lower rollers shaft is machined by the utilization of the most modern technological advances known to the industry, Grinding and finishing methods ensure mirror like finish and tempering with medium to low frequency heat treating equipment guarantees maximum strength.
7.Each bulldozer track roller is precision machined to house special high impact low wear bimetal bushings.
8.Lubrication oil of our bulldozer bottom rollers is selected carefully. It can lubricate shaft and bushing well to lower the wearing utmostly. And it can cool the roller perfectly. Those maximize the inner structure life.
9.Collars of bulldozer lower rollers are made by ductile iron. It shows exceptional resisitance to shock.
Technical requirement of D60A-8 Bulldozer Lower Roller
1. All parts shall be cleaned before assembly without any sundries;
2. Apply a small amount of clean oil to the grinding surface of the floating seal ring; ensure the axial direction after assembly
The displacement is 0.3-0.6 mm
3. Carry out the pressure test before oil injection, and there is no air leakage under the pressure of 0.5-0.6mpa;
4. After installation, inject clean sae80w-90 gear oil (the oil volume accounts for about the cavity
90% ~ 95% of the volume;
5. Run it in for 3-5 minutes after refueling to make it operate smoothly;
6. After the surface is clean, spray two coats of antirust paint.
KOMATSU BULLDOZER is a well-known name in the construction industry. The company is commitment to developing the best heavy-duty equipment with reliable and innovative designs. Over the years, KOMATSU has developed a range of bulldozers of different tons with a commitment to efficiency, durability, and customer satisfaction. In this article, we will discuss some of the KOMATSU BULLDOZER heavy-duty machines and their capabilities.
KOMATSU D37PXi-24: This is a 16.2-ton bulldozer and is one of the most versatile machines from KOMATSU. It comes with a highly advanced iMC 2.0 (Intelligent Machine Control) that is known for its accuracy, speed, and efficiency. This bulldozer is known for its fuel efficiency, improved visibility, and ability to work under any condition.
KOMATSU D51EX: This bulldozer is a 12.9-ton unit with a comfortable cab, making the operator comfortable while working. It boasts of KOMTRAX remote monitoring technology, which enables the operator to monitor the machine's vital parameters at any location. It is also designed to be fuel-efficient and low maintenance, which means lower operating costs.
KOMATSU D65EX: This is a 23.2-ton bulldozer with a powerful engine that provides excellent performance. This machine has a proven record for performance, durability and its ability to work in rough and challenging terrains. It has an advanced hydraulic system, which makes the machine faster and more efficient. The D65EX bulldozer is designed to reduce operator fatigue by offering maximum comfort and minimizing vibrations.
KOMATSU D85EX: This bulldozer has a 35.3-ton weight capacity and is known for its excellent pushing power. It comes with a fully sealed cab that protects the operator from dust particles and other debris. It is also equipped with KOMTRAX remote monitoring technology, which enables real-time monitoring of the machine's vital parameters. This bulldozer is renowned for its fuel efficiency, which reduces running costs for the operator.
In conclusion, KOMATSU BULLDOZER has successfully developed a range of heavy-duty machines that cater to different needs in the construction industry. The bulldozers are reliable, durable, with features that enhance efficiency and reduce operating costs. Furthermore, they have the latest technology that makes them easy to use, resulting in cost-effective solutions for any construction project.
Komatsu part number and Models for bulldozer lower rollers Available:
Partnumber:201-30-44000,Model:D20A-5,6,7/D20P-5,6,7/D20PL-6/D20PLL-6/D20Q-5,6,7/D20S-5,6,7/D21A-5,6,7/D21E-6/D21P-5,6,7/D21P-6A/D21P-6B/D21P-6,7/D21S-5,6/D21S-6A/21S-7
Partnumber:111-30-00274,Model:D30A-15,D30S-15/D31A-15,16,17/D31E-18/D31P-16,17,18,20/D31P-16A,17A,20A/D31PL-16,17,18,20/D31PLL-16,17,18,20/D31Q-16,17,18/D31S-15,6,17,18,20/D37E-1,3,5/D37P-1,2,5
Partnumber: 662823C92,Model: D32E/D32P/D38E/D38P
Partnumber: 621481C94,Model: D39E/D39P
Partnumber:131-30-56100,Model:D40A-1,3/D40F-3/D40P-1,3/D40PL-1,3/D40PLL-1,3/D41A-3/D41A-3A/D41E-3/D41P-3/D41Q-3/D41S-3/D45A-1/D45E-1/D45P-1/D45S-1/D50A-16,17/D50F-16,17/D50P-16,17/D50PL-16,17/D50S-16/D53A-16,17/D53P-16,17/D53S-16,17/D55S-2,3/D57S-1/D57S-1B/D58E-1/D58E-1A/D58E-1B/D58P-A/D58P-1B/ D63E-1/D63E-1A
Partnumber:131-30-56200,Model:D40A-1,3/D40F-3/D40P-1,3/D40PL-1,3/D40PLL-1,3/D41A-3/D41A-3A/D41E-3/D41P-3/D41Q-3/D41S-3/D45A-1/D45E-1/D45P-1/D45S-1/D50A-16,17/D50F-16,17/D50P-16,17/D50PL-16,17/D50S-16/D53A-16,17/D53P-16,17/D53S-16,17/D55S-2,3/D57S-1/D57S-1B/D58E-1/D58E-1A/D58E-1B/D58P-A/D58P-1B/D63E-1/D63E-1A
Partnumber:141-30-00577,Model:D60A-6,7/D60E-7,8/D60F-7,8/D60F-7A/D60F-8A/D60P-7/D60PL-7,8/D60S-7,8/D65A-6,7,8/D65P-7,8/D65S-7/8/D66S-1/D68E-1/D68P-1
Partnumber:141-30-00587,Model:D60A-6,7/D60E-7,8/D60F-7,8/D60F-7A/D60F-8A/D60P-7/D60PL-7,8/D60S-7,8/D65A-6,7,8/D65P-7,8/D65S-7/8/D66S-1/D68E-1/D68P-1
Partnumber:14X-30-14100,Model:D65A-8/D65E-7,8/D65E-12/D65EX-12/D65P-12/D65P-8/D65PX-12/D75S-1/D85ESS-2A
Partnumber:14X-30-14200,Model:D65A-8/D65E-7,8/D65E-12/D65EX-12/D65P-12/D65P-8/D65PX-12/D75S-1/D85ESS-2A
Partnumber: 154-30-00505,Model: D80A-12/D85A-12
Partnumber: 154-30-00405,Model: D80A-12/D85A-12
Partnumber:155-30-00127,Model:D75S-3,5/D80A-18/D80E-18/D80F-18/D80P-18/D83E-1/D83P-1/D85A-18/D85A-21/D85E-18/D85E-21/D85P-18/D85P-21/D95S-1/D95S-2/
Partnumber:155-30-00117,Model:D75S-3,5/D80A-18/D80E-18/D80F-18/D80P-18/D83E-1/D83P-1/D85A-18/D85A-21/D85E-18/D85E-21/D85P-18/D85P-21/D95S-1/D95S-2/
Partnumber: 175-30-00489,Model: D135A-1/2/D150A-1/D155A-1/2
Partnumber: 175-30-00499,Model: D135A-1/2/D150A-1/D155A-1/2
Partnumber: 17A-30-00070,Model: D155A-3/D155AX-3
Partnumber: 17A-30-00080,Model: D155A-3/D155AX-3
Partnumber: 178-30-16114,Model: D155C-1/D155S-1
Partnumber: 178-30-16124,Model: D155C-1/D155S-1
Partnumber: 17M-30-00220,Model: D275-2
Partnumber: 17M-30-00230,Model: D275-2
Partnumber: 195-30-00410,Model: D355A-1
Partnumber: 195-30-00420,Model: D355A-1
Partnumber: 195-30-00336,Model: D355A-3/5
Partnumber: 195-30-00346,Model: D355A-3/5
Partnumber: 195-30-01051,Model: D375-1/2/3
Partnumber: 195-30-01061,Model: D375-1/2/3
Partnumber: 198-30-00421,Model: D475-1/2
Partnumber: 198-30-00432,Model: D475-1/2
Workshop
D85P-18 bulldozer lower roller
Our factory
Painting
Cleaning
Assembly
Stock
About Us:Sanqi Machinery
Quanzhou Sanqi Engineering Machinery Co.ltd. Located in Quanzhou City which is the cultural captital of east asia,the starting point of the silk road at sea.We are a production-oriented enterprise which is engaged in casing,forging,machining,heattreamnt and assembly and commited to developing and manufacturing the udnercarriage parts of current world famaous brands.
we are equipped with machines,for example,table drill,radia drill,normal lathe,vertical lath,cnc lathe,milling machine,griding machine,sawing machine,sprocket heattreatment machine,idler heattreatment machine,track roller and carrier roller heattreatment,track link heattreatment machine,roller assembling line,casing lines and forging lines etc..
We are professional manufacturer of undercarriage parts and other related parts of crawler tracked machinery. Our products include track roller, carrier roller group, sprocket rim, front idler, track link ,track guard, track adjuster, boom cylinder assy, arm cylinder assy, bucket cylinder assy, bucket bushing, bucket pin, track bolt nuts, forging bucket teeth, bucket link, bucket side link, cutting edge and side cutters etc.. they are applicable for world famous brands and Chinese domestic brands like komatsu, hitachi, kobelco, kato, mitusbishi, Kubota, yanmar,Hyundai, doosan,Volvo, case, jcb, sany, xugong, liugong,zoomlion sunward etc..
FAQ
Q: What Is MOQ For The Order?
A: Generally speaking, the MOQ is a full container load of 20 feet container. Under this condition, the single cost can be lowered. if customers ask for less full container load. It is also acceptable.
Q: Are You A Manufacturer Or A Trader?
A: We are a manufacturer. We do forging and casting by ourselves. And our factory is located in Quanzhou city, Fujina, China.
Q: How About The Payment Terms?
A: TT 30 percent deposit,and TT 70percent balance after seeing the scan copy of bill of lading or LC at sight.
Q: How About The Delivery Time?
A: 3-7 days for stock goods,30-45 days for customized product.
Q: How Do You Offer Guarantee?
A: If parts are broken due to manufacturing problem, we will deduct the value for next order amount or offer you brand new one to replce.
Q: Could You Make Customer Logo?
A: Yes,we can make customer logos if it reachec the moq for customer logo order.
Q: Could We Be Your Exclusive Dealer?
A: Yes,our policy is that we will not let our customer to compete at the same place.
Q: How Could You Know If Our Parts Are Fitted To Machines?
A: Please offer us the detailed machine models or mounting sizes.
Q: If We Don't Have Drawings, Could We Develop A New Item?
A: Yes, you can offer us the main dimension. Then we can compare with our ready products and make a drawing for your checking.
Q: How Can You Control Your Quality?
A: When material come inside our factory, we need to analyze the material. And when front idlers and sprocket rims material are casted. We need to analyze the composition to see if the material is qualified or not. When track rollers, carrier rollers and front idlers are being assembled, we need to oil leakage testing. After several parts are heat treated, we need to check the hardness before all are done.And our inspectors will check the sizes at ramdom when parts are being machined or assembled. All of these can guarantee the parts with correct sizes and good quality.
